• Screws for fine adjustment for materials thinner than 0.5 mm
• Selector switch for single and continous stroke
• Working height 920 mm
• Single-padle foot switch with protective cover
• Anchor plates incl. dowels
• All-steel double-edged blade
• Blade opening 10/85
• Slots at 10 mm interverals parallel to the lower blade along the entire length of the table
• Extended, extendable support table
• Adjustable angle gauge with scale on the left and right
• Hold-down device with hard rubber strip to protect polished sheet metal
• Manual rear stop, adjustable from the front up to 750 mm, with digital display
• Safety package in accordance with CE: Rear safety protection via a 3-beam light barrier, including side protective guard

Accessories

• Pneumatically controlled sheet support to the front, Version 1 including sheet chute
• LED cutting edge illumination

• Screws for fine adjustment for materials thinner than 0.5 mm
• Selector switch for single and continous stroke
• Working height 920 mm
• Single-padle foot switch with protective cover
• Anchor plates incl. dowels
• All-steel double-edged blade
• Blade opening 10/85
• Slots at 10 mm interverals parallel to the lower blade along the entire length of the table
• Extended, extendable support table
• Adjustable angle gauge with scale on the left and right
• Hold-down device with hard rubber strip to protect polished sheet metal
• Manual rear stop, adjustable from the front up to 750 mm, with digital display
• Safety package in accordance with CE: Rear safety protection via a 3-beam light barrier, including side protective guard

Accessories

• Pneumatically controlled sheet support to the front, Version 1 including sheet chute
• LED cutting edge illumination

Standard equipment includes

• Patented eccentric quick-clamping mechanism for changing tools on the top rail and bending rail with a single hand movement
• Multi-stage top rail drive for four different tool heights
• Goat’s foot blade, 130 mm high, 30°, sharp, foot width 40 mm, clearance 26 mm, clearance 110 mm
• Combined folding rail, 120 x 12/15 mm, clearance 77 mm, segmented, including corner pieces
• Bottom beam blade, clearance 55 mm, segmented, including corner parts
• Tool division: 30/50/70/100/150/200/250/250/300 2×75 mm
• Clamping beam with sheet metal shelf (tool tray)
• Stand with shelf, including tool tray
• Adjustable folding angle adjustment and folding angle indicator
• Foot pedal for opening and closing the clamping beam
• Machine on four casters: 2 fixed casters and 2 steering casters, lockable;steering castor ist height-adjustable with handle front side right)

Accessories

•  Variable support brackets, 600 mm, with scale, slideable on guide rail, including 2 tilt stops

The extensive standard equipment includes:

• 1,550 mm working length / sheet thicknesses up to 1.75 mm
• Segmented folding blade, 100 x 15 mm, including corner segments
• Segmented lower beam tooling with plug-in system and corner segments
• Patented eccentric quick-clamping system for fast tool changes
• Two-stage upper beam drive for different tool heights
• 110 mm upper beam stroke for versatile bending profiles
• Integrated bending angle display
• Foot pedal for convenient opening and closing of the upper beam
• Two adjustable backgauge arms with scale and tilting stops
• Gooseneck tools with 26 mm clearance for demanding bending applications

The extensive standard equipment includes

• 22.5° bending rail, directly bolted
• Foot lever mechanism for operating the upper rail
• Adjustable angle stop 0–180°
• Lower rail, one-piece WZS 220
• Working height 930 mm
• Tool set
• Bending rails WZS 100, approx. 700 N/mm², 15 mm and 25 mm

Accessories:

• Manual back gauge 6–750 mm, adjustable from the front with digital display, including support table
• Additional bending angle stop
• Pneumatic bending assist
• Base plate set AK (with support bearing), including dowels

Please contact our sales team for information on machine configuration.

Standard equipment

• NC positioning gauge Classic Cut, Touch-control on turnable panel, gauge length 6-750 mm
• Bilateral drives
• Sheet support, pneumatically controlled to the back, gauge length up to 1000 mm, sheet support table width max. 750 mm
• Pneumatcally controlled sheet support to the front with sheet shute max. 750 mm
• Obligatory CE safety package: rear guarding via 3-beam light barrier incl. side protection grid
• Foot switch

Optional equipment

• Blades designed for stainless steel instead of standard blades
• Back gauge 750 mm with ball screws
• Extended angle gauge right with electron. length measurement system, fine adjustment and lateral flip gauge on linear guide 1000 mm
• Closed table
• Sheet support table with steel balls
• Linear guide at the front for movable table support arms
• 2 movable support amrs for linear guide incl. T-slot and scale 1000 mm
• Motorized blade gap adjustment
• Cutting edge illumination LED
• Pneumatic hold-down device

• Fastrak with hydraulic drive
• Software control CFP 120 on swivelling arm, 12″ colour LCD-touchscreen display
• Crowning device automatic
• MAV 72 1 axis motorized drive in front, adjustment range 6 – 200 mm
• Sheet support table at the bottom beam with steel balls
• Goat’s foot tool h = 120 mm
